Fire-resistant WOODY I F
®
The system of fire-resistant wood-glass partitions and doors is suitable for the design and functional division of interiors. The profiles are made of glued solid oak. The uniform thickness of the frame and bottom profiles ensures a clean partition line with no rebound.
Fire doors and door assemblies in glazed frame or full frame designs to the thickness of the frame face on both sides and, thanks to the design with concealed hinges and self-closing mechanism, look clean without distracting surface components. More
Declaration of conformity:
Partition fire resistance:
Door assemblies fire resistance:
Cycle value:
Smokeproof enclosure:
WOODY_I_F_002_10.01.2024
WOODY_I_F_003_10.01.2024
EI 30 / EW 45 DP3
(partitions up to EI 60 DP1*)
EI 30 / EW 45 DP3
C5
Sa4; S200



TECHNICAL SPECIFICATIONS - FIRE-RESISTANT WALL
Description:
Use:
Profile material:
Partition filling:
Glass joint:
Partition thickness:
Silicone color:
Doors:
Hinge types:
Door closer types:
Lock types:
Handle type:
Declaration of conformity
glazed partition with fire resistance
fire-resistant door assemblies
non-load bearing interior partition | door with fire resistance
solid glued oak wood
laminated glass
silicone 5 mm
68 mm
milky
framed glass, wooden, fire-resistant doors
object hidden and adjustable
hidden
mechanical | electromechanical
self-locking panic lock
Süd Metall EN 179 | EN 1125
WOODY_I_F_002_10.01.2024
WOODY_I_F_003_10.01.2024
SURFACE FINISHING OF WOODEN PROFILES
WOODY I F FIRE-RESISTANT WALLS AND DOORS REFERENCES
Fire-resistant partitions - The perfect combination of aesthetics and safety
WOODY I F is a modern glazed system for partitioning fire compartments and fire closures. It combines elegance, functionality, and maximum protection of spaces. This certified structural system consists of fire-resistant partitions and custom-designed doors. It is ideal for interiors where safety and style are priorities.
THE HIGHEST LEVEL OF FIRE PROTECTION
The WOODY I F smoke-resistant door assembly complies with the Sa4; S200 classification according to EN 16034. It limits the penetration of cold and hot smoke up to 200°C and includes solid and glazed fire doors and partitions with resistance up to EI 60 DP3 for fixed parts and EI30/EW 45 DP3 for doors. The certified system ensures that both fire and smoke resistance requirements are met. The doors are tested for extreme use with 200,000 opening and closing cycles, equivalent to Class C5.
» TIP: Wood-glass partitions WOODY II SLIM or more robust WOODY II partitions without fire resistance
High-quality materials and environmentally friendly finish
The profiles of the partitions and door frames are made from premium solid oak, and treated with eco-friendly VOC-free oils. These oils preserve the natural texture of the wood, protect it from moisture and liquids, and are registered in the "Baubook" database of environmentally friendly products. This makes WOODY I F partitions suitable even for people with allergies.
CLEAN DESIGN WITH HIDDEN TECHNOLOGY
The WOODY I F partitions are equipped with top-quality components such as Simonswerk Tectus concealed hinges, ÜLock self-locking panic locks, and GEZE self-closers. The glazing beads' concealed fixing and the possibility of hiding the perimeter profiles in the surrounding structures ensure a minimalist appearance and clean lines.
Flexible design and high sound insulation
With laboratory-tested sound insulation of glazing up to 39 dB, WOODY I F partitions provide protection and a pleasant acoustic environment. The system allows individual design adaptations, including straight, rectangular, or segmented joints.
Tailored to any space
The WOODY I F system is designed and manufactured to meet specific customer requirements. It is installed on finished surfaces, minimizing alterations and ensuring a perfect connection to walls, floors, and ceilings. This system is ideal for public buildings, offices, and business premises.
THE INTEGRATION OF WOODY I F WITH WOODY I PARTITIONS
WOODY I F follows the design of the WOODY I system, which allows fire and non-fire partitions to have a uniform appearance in the same interior. They can be freely combined according to fire safety requirements.
For modern interiors, an elegant and secure solution
WOODY I F offers a superior combination of aesthetics, safety, and functionality. Contact us for more information and to design a solution tailored to your needs.
